Machine Number	8
Nominal Width	180
Serial	74325
Type	LWV 8/J
Year	2000
Year of Harness	2003
Location	El Salvador
View Video:

ADVANTAGES TO RAPIER LOOMS:
• More productive per Square Mt, less factory space!!
• Servo motor for warp beam.
• Servo motor for Pick control.
• Digital warp sensor controlling up to 30 denier warp denier.
• Automatic start and weft fixer.
• 50% less operator vs mugrip.
• Lower energy cost vs small loom of 1 Mt. Guaranteed Low weaving defects and jacquard mistakes.
• Staubli Jaquard is the Leader in the technology.
• Jaquard will not need to use floppy-can be sent directly via IP to the loom.
• Labels ready from the loom due professional thermofixing.

CHARACTERISTICS:

• Weaving System: Air Weaving Machine

• Base Loom: LWV / 8/J 8 Colors

• Weaving Width: 168 cm

• Jacquard Staubli: CX880

• Harness: Taffeta, 8 x 1152, @ 211 mm

• Warp: Polyester 70 - 100 den

• Warp Density: 54.6 - 109,2 ends per cm

• Weft Material: Polyester 50 - 200 dtex

• Weft Density: 20 - 60 picks per cm

• Speed: 950 / 800 rpm

• Cutting System: SCU2/SEL

• Cutting Control: MCD Label localizer in combination with MCS (Modular Cutting System)

• Year of Harness: 2003

• Year: 2000
