WOVEN LABEL LOOMS

MACHINE
MODEL
SERIAL
HARNESS TYPE
YEAR
to request a full length detailed video, click here
#122
MVC2-200
AN-95.30330
Taffeta
1996

CHARACTERISTICS

•   Hooks 768/524
•   Digi-Kast Electronic Warp Let-Off Control
•   Jacquard Machine Mueller
•   Type (Taffeta)
•   Welft Density 28 PPC
•   Magnet Cards: 17
•   Springs Harness
•   Thermo Fixation Devices With Electronic Control
•   Mudata Display Version 4
•   Motor Braker With Slow Motion
•   Control Cabinet
•   One Warp Beams
•   Sensor Regulator
•   Supply Voltage 3X220 V
•   Frecuency 60HZ
•   Loom Will Be Shipped With Yarn Drawn-In (Warp With 1,840 Threads)
•   Speed up 1100 RPM
•   Number Of Repetitions 15
•   Maximum Width Repetition 30MM
