• Hooks : 1152
• Weft insertion by rapier 8 colors
• Digi-Kast electronic warp let-off control
• Jacquard machine Mueller
• Type SPE 1536/ 12/03
• Magnet cards: a. 32 b.32
• Magnets per card: a. 20 b. 16
• Springs harness
• Thermo fixation devices with electronic control
• Mudata display: version 4
• Weft accumulator ( IRO) 8 units
• Latest weft extention control
• Use weft color selector
• Slitting elements 50 units
• Motor brake with slow motion
• Control cabinet
• One warp beams
• One shaft winding
• Warp sensor regulator
• Loom will be shipped with yarn drawn-in (warp with threads): 5,796
• Speed: Up 600 RPM
• Repetitions harness: 5
• Width repetition: 200mm
• Hooks per color: 12
|
